Turf Reinforcement Mesh, Plastic Grid for Grass Root Protection

PVC or plastic mesh is ideal for controlling pedestrian and vehicle movement inside the premises while providing protection for the turf areas. Using pvc mesh panels as protective turf reinforcement mats are popular and economical ways to park areas grass guarding. The turf mesh can protect the grasses from being cut or hurt from the roots. Newly developed three dimensional structured plastic net is designed for grass growing in slope areas. We offer both traditional flat sheet plastic and new type 3D plastic netting for grass reinforcement protection.

HDPE Mesh Grass Protective Grid

Extruded PVC Flat Net Grass Guarding Mats

Outdoor durable and elegant turf mesh mattress:

Parking Area Grass Protection PVC Mesh Mats



3D Grass protection plastic net for slope areas:

3D HDPE Plastic net is a kind of three-dimensional structure suitable for water and soil conservation of new materials. It can effectively prevent water loss and soil erosion, increase the green area, improve the ecological environment.

Materials: HDPE

3d plastic net Advantages and effect:

1. Used before the grass grow, to keep the land surface from wind and rain erosion;
2. With plant formation, the composite protective layer can withstand high water level and large flowing velocity of water flow;
3. Alternative materials of concrete, asphalt, stone, it is mainly used for highway, railway, river channel, embankment, slope and slope protection.
4. Using 3D Vegetation protection plastic net adopts mechanical to spray and sow grass of highway slope greening, such as the smooth surface after construction, construction technology is simple, can greatly reduce the project cost;
5. Three-dimensional plastic net with polymer materials and uv stabilizer, the chemistry stability is high.

Flat Vinyl mesh or pvc mesh / plastic netting for grass protection in Parking areas:
Rigid plastic mesh made of hdpe
Mmesh type:diamond,square, hexagonal
Mesh size:2-70mm
Mesh roll :1m,1.5m,2m,2.5m
Roll length:30-100m


High density extruded turf reinforcement mesh
material:hdpe
mesh size:25*25mm(diamond or hexagonal)
roll width:1m,1.5m,2m ,2.5m
roll length:20-50m
weight:300-700gsm
color:dark green,green,black


PVC based turf reinforcment mesh for grass protection is easy to handle, setup, move & store.
Light weight.
Economic.

Processing of Flat Extruded Plastic Mesh:
Plastic flat mesh ( also known as plastic net ) of plastic raw materials in the extruder heating melt, through the extrusion into a number of holes and die special rotating head, molten plastic flows through the die opening pore formation of two shares of melt wire, due to head rotation, two strand of wire discontinuous converging at a point, to form a network, then cooling shaping into network.

Specification of Turf Reinforcement Mesh for Grass Guarding:

Material

PE(Polyethylene), PP(polypropylene)

Length

unlimited

Hole size

Length :10mm-12mm     Height:0.9mm-5.8mm

Mesh

25-100mesh

Width

1-2m

Color

white, black, green , blue, orange, yellow, red etc.


Extruded Flat PVC Mesh for Turf Reinforcing:

Mesh Wide(m)

Aperture(cm)

Thick(mm)

Diameter(cm)

Weight(kg/roll)

0.5

0.6

1

20-25

30

0.8

1.2

1

20-25

30

1

5

1

20-25

30

1

6

1

20-25

30

1.25

2

2

20-25

30

4.25

1.5

1.5

25

25

4.25

1

1

25

25

1.25

0.6

1

25

30

1.25

0.8

1

25

40

1.2

0.8

1.2

30

35

2

1

1.2

30

40

2

1.5

2

30

50

2

2.5

2.5

45

50

2

3

2.5

45

55

2.2

2.5

2.5

50

60

2.5

1.5

2

50

80

2.5

3.5

3

55

65

2.5

2

2.5

50

70

2.5

3

3

50

75

3

3

4.5

50

85

4

3

4.5

50

90



Features of PVC Turf Reinforcement Mesh:

Turf guarding mesh can keep its good looking for years which are longer than other materials.
Low maintenance: you need not to paint or stain.
It will not crack, chip or peel.

:
We adopt the process taht injects a U.V. protector in the entire profile, having 100% coverage.
